Description
PM111 LHW CHIRP 2kW Wide-Beam Chirp-Ready Pocket/Keel Mount - No Connector
Get more coverage under your boat with Airmar’s unique wide-beam, high-frequency, Chirp-ready transducer. The high band operates across a frequency range of 150 to 250 kHz and has a fixed 25° beam for all frequencies. The high-frequency band results in superior resolution. The constantly wide beam provides twice the coverage and excellent fish arches on the display compared to most high-frequency, narrow-beam transducer options.
The high wide is the ideal choice for both inshore and pelagic fishing, where resolution and maximum coverage under the boat are essentially down to 152 m (500').
The low-frequency band and 2 kW of power also support great deep-water performance. Get the best of both worlds with Airmar’s dual-frequency, Chirp-ready transducer with wide-beam coverage.
Features:
The depth and fast-response water-temperature sensor
2 kW of power for great deep-water performance from the low frequency
2 kW low frequency: 38 to 75 kHz
19° to 10° port-starboard beamwidth
10° to 5° fore-aft beamwidth
Maximum depth of 1,829 m (6,000')
1 kW high frequency: 150 to 250 kHz
25° constant beamwidth
Maximum depth of 152 m (500')
137 kHz of total bandwidth from one transducer
Covers popular fishing frequencies of 50, 68, and 200 kHz plus everything else in the bandwidth
High frequency delivers superior shallow-water performance, bottom detail, and fish-target separation
High wide beamwidth yields more coverage for detecting fish in the upper-water column
Urethane housing designed for custom mounting in a cavity
Also available in an external (R109LHW) mount
Exclusive Xducer ID® technology
Specifications:
Weight: 13.6 kg (30 lb.)
Recommended Boat Length: 12 m (40') and above
Hull Material: Solid fiberglass only
Hull Deadrise: Accommodates any deadrise angle based on custom cavity construction
This product may not be returned to the original point of purchase. Please contact the manufacturer directly with any issues or concerns. Brochure (pdf)
